For over 30 years Tiger Tanks has been engineering and manufacturing excellent quality above-ground galvanized steel water storage tanks. These factory-built tanks are available in 25 different models ranging in size from 1,000 gals to 30,000 gal. You have the choice of non-coated or NSF epoxy coated tanks for potable water storage. This interior epoxy coating protects the tank from the corrosive mineral content present in most stored well water. The application of this coating can add many years to the lifespan and overall service of these water tanks. Tiger Tanks can be built to American Water Works Association (AWWA) and National Fire Protection Association (NFPA) standards. Tiger galvanized water tanks can be painted in a variety of colors to suit your individual needs.
General Information
- Galvanized water tanks by Tiger Tanks range in size from 1000 gallons to 30,000 gallons
- 25 different models to choose from
- Available in 12 gauge and 10 gauge steel
- 20+ year lifespan (with epoxy coating)
- Applications for your steel tank includes drinking water, fire protection, irrigation, disaster preparedness, rainwater collection
- Resilient despite extreme elements, such as temperature (-40 to 130 degrees), winds and wildfires
- 3 year warranty for non-epoxy coated & 10 year for epoxy coated
- Additional fittings can be installed anywhere on the tank to meet your specific needs
- These water tanks are made for above ground storage of water only - Do not bury these, above-ground only water tanks
- These water tanks are rated for atmospheric pressure only - Do not use as vacuum or pressure tanks
Galvanized Steel Tanks by Tiger Tanks
Tank dimensions and fitting placement may vary slightly. Specifications are subject to change without notice.
| Capacity | Diameter | Height | Weight | Standard Accessories |
|---|---|---|---|---|
| 1000 gal | 6' 6" | 4' | 724 lbs | 18" manway, 4 - 2" (or smaller) fittings, 4" fire fitting (w/ anti-vortex) |
| 1500 gal | 8' | 4' | 1,062 lbs | 18" manway, 4 - 2" (or smaller) fittings, 4" fire fitting (w/ anti-vortex) |
| 2000 gal | 6' 6" | 8' | 1,200 lbs | 18" manway, 4 - 2" (or smaller) fittings, 4" fire fitting (w/ anti-vortex) |
| 2500 gal | 7' 4" | 8' | 1,400 lbs | 18" manway, 4 - 2" (or smaller) fittings, 4" fire fitting (w/ anti-vortex) |
| 2500 gal | 8' 5" | 6' | 1,286 lbs | 18" manway, 4 - 2" (or smaller) fittings, 4" fire fitting (w/ anti-vortex) |
| 2500 gal | 10' 4" | 4' | 1,310 lbs | 18" manway, 4 - 2" (or smaller) fittings, 4" fire fitting (w/ anti-vortex) |
| 2800 gal | 7' 8" | 8' | 1,400 lbs | 18" manway, 4 - 2" (or smaller) fittings, 4" fire fitting (w/ anti-vortex) |
| 3200 gal | 8' 3" | 8' | 1,631 lbs | 18" manway, 4 - 2" (or smaller) fittings, 4" fire fitting (w/ anti-vortex) |
| 3750 gal | 9' | 8' | 1,750 lbs | 18" manway, 4 - 2" (or smaller) fittings, 4" fire fitting (w/ anti-vortex) |
| 4200 gal | 9' 6" | 8' | 1,913 lbs | 18" manway, 4 - 2" (or smaller) fittings, 4" fire fitting (w/ anti-vortex) |
| 5000 gal | 10' 4" | 8' | 2,125 lbs | 18" manway, 4 - 2" (or smaller) fittings, 4" fire fitting (w/ anti-vortex) |
| 5000 gal | 8' 5" | 12' | 2000 lbs | 18" manway, 4 - 2" (or smaller) fittings, 4" fire fitting (w/ anti-vortex) |
| 5000 gal | 12' | 6' | 2,200 lbs | 18" manway, 4 - 2" (or smaller) fittings, 4" fire fitting (w/ anti-vortex) |
| 5500 gal | 11'" | 8' | 2,275 lbs | 18" manway, 4 - 2" (or smaller) fittings, 4" fire fitting (w/ anti-vortex) |
| 6250 gal | 11' 6" | 8' | 2,500 lbs | 18" manway, 4 - 2" (or smaller) fittings, 4" fire fitting (w/ anti-vortex) |
| 7500 gal | 10' 4" | 12' | 2,700 lbs | 18" manway, 4 - 2" (or smaller) fittings, 4" fire fitting (w/ anti-vortex) |
| 10000 gal | 10' 4" | 16' | 3,315 lbs | 18" manway, 4 - 2" (or smaller) fittings, 4" fire fitting (w/ anti-vortex) |
| 10000 gal | 12' | 12' | 3,400 lbs | 18" manway, 4 - 2" (or smaller) fittings, 4" fire fitting (w/ anti-vortex) |
| 10000 gal | 9' 9" | 18' | 3,200 lbs | 18" manway, 4 - 2" (or smaller) fittings, 4" fire fitting (w/ anti-vortex) |
| 12500 gal | 11'6" | 16' | 3,800 lbs | 18" manway, 4 - 2" (or smaller) fittings, 4" fire fitting (w/ anti-vortex) |
| 15500 gal | 11' 6" | 20' | 5,700 lbs | 18" manway, 4 - 2" (or smaller) fittings, 4" fire fitting (w/ anti-vortex) |
| 20000 gal | 12' | 24' | 6,800 lbs | 18" manway, 4 - 2" (or smaller) fittings, 4" fire fitting (w/ anti-vortex) |
| 20000 gal | 13' 9" | 18' | 7,200 lbs | 18" manway, 4 - 2" (or smaller) fittings, 4" fire fitting (w/ anti-vortex) |
| 25000 gal | 13' 11" | 22' | 7,540 lbs | 18" manway, 4 - 2" (or smaller) fittings, 4" fire fitting (w/ anti-vortex) |
| 30000 gal | 13' 11" | 26' | 9,800 lbs | 18" manway, 4 - 2" (or smaller) fittings, 4" fire fitting (w/ anti-vortex) |
Accessories Included with each tank
- (1) 18" square lockable top manway or (1) 18" bolted side manway
- (1) Mushroom type screened vent
- (1) 4" Fire Fitting and (3) smaller flanged fitting connections
- Exterior finish color (per customer choice)
- Interior zinc spray on liner for weld seams
- Exterior bottom coated weld seams
Accessories offered with an additional charge
- Flanged fitting connections up to 12" in diameter
- Liquid level indicators
- Gravel rings
- OSHA caged ladders
- Seismic restraints
- NSF-61 epoxy coated lining
Tiger tanks also manufactures these other high quality tank products:
- Horizontal hydro-pneumatic tanks 75 - 150 psi
- Vertical hydro-pneumatic tanks 75 - 150 psi
- Horizontal UL-142 diesel storage tanks
- Vertical UL-142 diesel storage tanks
- Horizontal UL-142 diesel storage tanks with secondary containment
- UL 2035 above ground rectangular and cylindrical fireguard tank vaults for gasoline storage
Note: All Tiger Tanks water tanks are available at the factory in Bakersfield, CA. Freight rates available upon request. Tanks are delivered and set using the tiger tank hydro crane.
